An SMT feeder calibration jig is a crucial tool for ensuring precise component placement in surface mount technology (SMT) assembly lines by accurately aligning component feeders.
Purpose
Offline calibration: Allows feeders to be checked and adjusted without stopping the SMT line.
Pitch accuracy: Verifies feeder advancement (2 mm, 4 mm, 8 mm, 12 mm).
Sensor testing: Confirms optical/electrical sensors detect tape holes and component presence.
Motor check: Ensures servo/pulse motors drive correctly.
Maintenance: Identifies worn gears, springs, or connectors before they cause placement errors.
Typical Features
Rigid base: ESD‑safe platform with feeder mounting slots.
Measurement scale: Micrometer or ruler markings for pitch accuracy.
Electronics interface: Power and signal connectors to simulate machine input.
Compatibility: Available for Samsung, Yamaha i‑Pulse, Panasonic, ASM Siplace, Universal GSM/Genesis feeders.
Delivery lead time : in stock
Payment : TT , PayPal, CreditCard, Western Union
MOQ : 1PCS
